►Intelligent CNC Leveling System: achieves high-speed continuous leveling at line speeds of 8-30 meters per minute.
►Supports fully automatic vision: based side bend correction, significantly enhancing strip straightness and geometric accuracy.
►Efficient In-Line Continuous Production
►Precision Leveling Capabilities: Features a 21-roll working structure, achieving post-leveling strip flatness ≤0.10mm/1.5×35×200mm and straightness ≤0.30mm/1.5×35×1000mm
►Wide Material Compatibility: Suitable for metal coils with tensile strength ≤300MPa, processing carbon steel, stainless steel, and non-ferrous metal strips with thicknesses of 0.5-3mm and widths ≤80mm (theoretical maximum 110mm).
| Item | Specification |
| Leveling Capacity | σb ≤ 300 MPa; Workpiece cross-section B×C ≤ 600 mm² |
| Strip Thickness (B) | 0.5–3 mm |
| Strip Width (C) | ≤ 80 mm (theoretical max: 110 mm) |
| Strip Length (L) | ≥ 1500 mm |
| Feeding Height | H = 1100 mm (from floor level) |
| Leveling Accuracy | Flatness ≤ 0.10 mm / 1.5×35×200 mm Straightness ≤ 0.30 mm / 1.5×35×1000 mm |
| Line Speed | 8–30 m/min |
| Work Roll Quantity | 21 pcs |
| Work Roll Diameter | 25 mm |
| Main Motor Power | 7.5 kW |
| Overall Dimensions (L×W×H) | 3000 × 1200 × 1800 mm |
| Net Weight | 2000 kg |
